iLX-W650 and KTA-200M Package with PowerStack™

7-Inch Shallow-Chassis Multimedia Receiver and Power Pack Mono Amplifier Package with PowerStack™
Arrow
Arrow

$564.89

Learn More at
Where to Buy

Find a local or online retailer

Learn More at
Where to Buy

Find a local or online retailer

A Simple Way to Add Bass

Product Overview

Experience the gateway to Alpine sound with an all-in-one solution that upgrades your vehicle's technology and gives you incredible subwoofer power.

FeaturesArrow

What’s Included
  • One (1) iLX-W650 7-inch Mech-Less Audio/Video Receiver (2.4” mounting depth)
  • One (1) KTA-200M Mono Power Pack Amplifier (7” x 1.5” x 3.5”)
  • Wiring harness (15A Fuse)
  • PowerStack mounting bracket
  • Amp power kit

Alpine’s iLX-W650 7” Mech-Less Audio/Video Receiver
  • 7” anti-glare WVGA display with capacitive touch screen
  • Two-finger swipe user interface (volume up, volume down, skip forward, skip back, and pause)
  • 2.4” shallow mount chassis design
  • Works with Apple CarPlay®
  • The Google Assistant is available on Android Auto™
  • Bluetooth® built-in for hands-free calling and audio streaming
  • SiriusXM-Ready® (SXV300 Connect Vehicle Tuner Kit sold separately; SiriusXM subscription required)
  • Works with Pandora® Music for iPhone and Android phones
  • Rear camera input (camera sold separately)
  • FLAC/MP3/WMA/WAV/AAC/ music playback via USB
  • AVI/MP4/MPG/MOV/WMV USB video playback
  • JPG/PNG/BMP USB photo viewer
  • MediaXpander®
  • Compatible with most factory steering wheel audio controls (adapter required)
  • 2 camera input (Rear, Front, Side, Other) configurations
  • Rearview camera distance guide display
  • External microphone included
  • 1.0m right angle USB cable included

KTA-200M Mono Power Pack
  • Alpine’s Exclusive Dynamic Peak Power (DPP) Technology  
  • Remote Bass-Knob ready with the RUX-KNOB.2 (sold separately) 

Tech SpecsArrow

Alpine’s iLX-W650 7” Mech-Less Audio/Video Display
  • Built-in amplifier (16 watts RMS/45 peak x 4 channels)
  • 3 PreOuts (True 4V)
  • 24 Bit DAC
  • 3-Band Graphic EQ
  • 9-band Parametric EQ
  • High pass crossover / low pass crossover
  • 6-channel time correction
  • CTA-2006 compliant

KTA-200M Mono Power Pack
  • Product Dimensions: 7” x 1.5 “ x 3.5 “
  • Alpine’s Class D Amplifier Circuit w/ Dynamic Peak Power (DPP) 
  • 200W x 1 RMS (4Ω, 14.4V, ≤1% THD+N) 
  • 200W x 1 RMS (2Ω, 14.4V, ≤1% THD+N) 
  • 400W x 1 DPP (4Ω, 14.4V, ≤1% THD+N) 
  • S/N >80dB (ref. 1W into 4Ω) 
  • THD+N ≤0.1% (ref. 10W into 4Ω) 
  • 20-400Hz Frequency Response (+/- 3dB)
  • Single-side 22-pin connector 
  • RCA inputs (Low range=0.2-4V) 
  • Sound controls; Crossovers-Off/60Hz/80Hz/120Hz Linkwitz Riley LP Filter @ -24dB/Oct. (selectable); Input gain setting (variable) 

Experience the Gateway to Alpine Sound

If you’re looking to make a noticeable impact in your sound system, experience the gateway to Alpine sound with the iLX-W650 and KTA-200M Package with PowerStack™. This all-in-one solution upgrades your vehicle's technology with a 7-inch display with smartphone capability, through Apple CarPlay or Android Auto, and a mono amplifier designed as an easy, add-on bass solution for incredible subwoofer power.

A Simple Way to Add Bass

Adding a subwoofer is the best way to make a noticeable impact in your sound system, but what if you don’t have space in your vehicle, or your budget, to add both a subwoofer and an amplifier? The iLX-W650 and KTA-200M Package with PowerStack™ occupies the same amount of space as a traditional 2-DIN radio yet allows you to easily add a subwoofer to your sound for the bass you’ve been craving. Thanks to Alpine’s exclusive Dynamic Peak Power (DPP) technology, the package can rise from 200-watts to 400-watts to meet the peak demands of your music and then roll back to maintain efficiency. A voltage adapting input circuit is included to maintain maximum source signal level without clipping so your bass comes out clean, even at high volumes.

Apple CarPlay

The iLX-W650 and KTA-200M Package with PowerStack™ “Works with Apple CarPlay” and lets iPhone users make and receive calls, access text messages, play music, and get direction in a way that allows them to stay focused on the road. Apple CarPlay is accessed through the capacitive touch screen or the mic button to activate Siri voice control and is compatible with iPhone 5 and later (iPhone must be connected via Apple lightning cable).

Android Auto

The iLX-W650 and KTA-200M Package with PowerStack™ includes Android Auto and works with the Google Assistant (requires both a USB cable and Bluetooth connection; requires an Android phone running 5.0 [Lollipop] or higher and the Android Auto app). To access the Google Assistant on Android Auto, say “OK Google” or select the mic button. Google Assistant in Android Auto allows users to play their favorite music, get driving directions to their destination, interact with smart home devices and reply to text messages – hands free.

Get Hands-Free Smartphone Control

Use your smartphone while keeping your hands on the wheel with Apple CarPlay, Android Auto, and built-in Bluetooth calling and audio streaming. The 7-inch screen is designed to match the app icons on your smartphone so you can find what you need fast. Use two-finger swipe motions on the capacitive touchscreen or go handsfree with voice commands on the external microphone to activate your apps, make calls, send texts, and get directions.

Find Your Next Adventure

Let the iLX-W650 and KTA-200M Package with PowerStack™ get you to your next adventure with smartphone navigation, available on Apple CarPlay, Android Auto, or Waze. Either use the “voice” button located on the receiver or your smartphone to get turn-by-turn directions. Add a front or rear-view camera to your vehicle (sold separately) and control the angles from the large, 7-inch, anti-glare screen. A built-in rear-view camera distance guide display makes blind spots a distant memory.

Complete Your Sound System

The iLX-W650 and KTA-200M Package with PowerStack™ gives you a simple way to add bass to your sound system by adding a subwoofer from Alpine’s S-Series subwoofers, the best in performance value. The iLX-W650 and KTA-200M Package with PowerStack™ is matched in both power and performance with the new S-SB10V Single 10-inch Alpine Halo S-Series Preloaded Subwoofer Enclosure with ProLink™.

Built-In Features

By offering numerous entertainment options, the iLX-W650 knows how to keep you entertained on the road.

Made for iPhone

It’s convenient to control your iPod or iPhone in the car – enjoy seamless operation of your iPod in addition to full control of all your favorite media sources. Control all search options of your iPod directly from the iLX-W650 and KTA-200M Package with PowerStack™ via Playlist, Artist, Album, Song, Genre, Podcast or Composer. The USB connection allows for high-quality iPod/ iPhone playback and delivers an even faster access speed so you’ll find songs as quickly as you expect to find them on your iPod/ iPhone.

SiriusXM-Ready

Upgrade your sound experience and expand your entertainment choices by adding SiriusXM satellite radio to your iLX-W650 and KTA-200M Package with PowerStack™. The iLX-W650 and KTA-200M Package with PowerStack™ is SiriusXM-Ready and connects to the SiriusXM SXV300 Connect Vehicle Tuner Kit (sold separately, subscription required). SiriusXM features include: album art; display of channel logos; pause, rewind and replay up to 60 minutes of content while listening to satellite radio; start songs from the beginning when tuned to any favorite music channel using TuneStart; scan and select songs on favorite music channels with TuneScan.

Works with Pandora

You can listen to Pandora music from either your Android smartphone or iPhone through a direct source or through Apple CarPlay (using a lightning cable) and Android Auto (using a USB cable and Bluetooth connection) on your iLX-W650 and KTA-200M Package with PowerStack™.

iLX-W650 and KTA-200M Package with PowerStack™
